Pulsar Axion XQ19 Compact Hand Held Thermal Imager

The Pulsar Axion XQ19 Compact thermal imager is a powerful and ultra-portable thermal imaging monocular, engineered for hunters, wildlife observers, and outdoor professionals seeking reliable thermal performance in a lightweight package.

Despite its compact size, the Axion XQ19 packs impressive technology—delivering clear thermal imagery, long-range detection, and robust durability in all weather conditions.

The Pulsar Axion XQ19 Compact is a powerful and ultra-portable thermal imaging monocular, engineered for hunters, wildlife observers, and outdoor professionals seeking reliable thermal performance in a lightweight package.

Despite its compact size, the Axion XQ19 packs impressive technology—delivering clear thermal imagery, long-range detection, and robust durability in all weather conditions.

Built with advanced features and Pulsar’s latest imaging technology, the Axion XQ19 strikes the perfect balance between size, power, and affordability.

Despite its compact dimensions, the Axion XQ19 Compact delivers impressive performance thanks to its sensitive 384×288 thermal sensor and industry-leading <18 mK NETD thermal sensitivity. This allows it to deliver consistently sharp thermal imagery, even in low-contrast environments such as fog, rain, or cold mornings.

Its fast 19mm f/1.0 objective lens provides a wide field of view of over 19°, making it ideal for scanning open ground, treelines, or valley edges. Combined with a detection range of up to 750 metres, the Axion XQ19 is a highly capable thermal spotter for short to mid-range observation.

Advanced Thermal Sensor

Equipped with a 384×288 resolution sensor with a 17µm pixel pitch and <18 mK NETD sensitivity, the Axion XQ19 delivers high-contrast thermal images, making it easier to distinguish animals, humans, or objects from their background.

Long Detection Range

With a 19mm f/1.0 lens, the Axion XQ19 can detect heat signatures at distances up to 750 metres, providing excellent reach for spotting wildlife, managing pest species, or conducting surveillance tasks.

Wide Field of View

A 19.2° field of view ensures broad area coverage with less panning, ideal for scanning hedgerows, open fields, or woodland edges during dusk or total darkness.

AMOLED Display

The high-quality 640×400 AMOLED display offers crisp image reproduction with excellent contrast, helping you identify and track subjects with ease.

Colour Palette Modes

Select from eight different thermal colour palettes including White Hot, Black Hot, Red Hot, and Rainbow, enabling you to adapt the image to your environment or viewing preference.

Built-in Recording and Connectivity

The Axion XQ19 includes an integrated video and photo recorder, allowing you to capture stills and footage directly onto internal memory. It also features Wi‑Fi connectivity and supports Pulsar’s Stream Vision 2 app, enabling:

• Real-time image streaming to your mobile device

• Remote control of the unit

• Wireless firmware updates and file transfers

Durable, Lightweight Design

Constructed from a rugged magnesium alloy housing, the Axion XQ19 is shock-resistant and waterproof to an IPX7 rating, meaning it can withstand rain, splashes, and accidental submersion. Weighing approximately 300 grams, it is easy to carry in a pocket or pouch for extended periods without fatigue.

Pulsar Axion XQ19 Compact – Technical Specifications

• Sensor Resolution: 384×288 pixels

• Pixel Pitch: 17µm

• Thermal Sensitivity (NETD): <18 mK

• Objective Lens: 19mm f/1.0

• Field of View (Horizontal): 19.2°

• Detection Range: Up to 750 metres

• Display Type: AMOLED

• Display Resolution: 640×400 pixels

• Magnification: Fixed base magnification (check with manufacturer for exact value)

• Digital Zoom: TBC (if known, can be added here)

• Colour Palettes: 8 selectable thermal palettes

• Video Recorder: Built-in photo and video capture

• Internal Memory: Yes (specification not listed – check manual for capacity)

• Wi‑Fi Connectivity: Yes – supports Pulsar Stream Vision 2 app

• Mobile App: Stream Vision 2 (Android & iOS)

• Battery Type: Pulsar APS3 rechargeable battery pack

• Battery Life: Up to 8 hours continuous use

• Charging Interface: USB-C

• Housing Material: Magnesium alloy

• Waterproof Rating: IPX7 (submersible to 1m for 30 mins)

• Operating Temperature Range: TBC (typically -25°C to +40°C)

• Dimensions: Compact format (exact dimensions can be added if known)

• Weight: Approx. 300g
